Clamping arm out of aluminium
For vertical clamp 6958AU and 6958AT, load lever 30 mm, max. clamping force 0,8 kN, max. operating pressure 100 bar
Order no.
324475
Design:
Aluminium.
Application:
For vertical clamp 6958AU and 6958AT.
Note:
Clamping pressure, leverage, flow volume and clamp arm weight must always be observed. Max. operating pressure 100 bar.
* X1 = level length at 90°
| Order no. | 324475 |
|---|---|
| Product type | Clamping arm |
| Max. clamping force [kN] | 0.8 |
| Max. operating pressure [bar] | 100 |
