| Order no. | Size | Height
[mm] | Length
[mm] | Weight
[g] | Availability | Your Price |
| 94623 | 1 | 29 | 31 | 40 | | |
| 94649 | 3 | 29 | 40 | 70 | | |
| 94664 | 5 | 61 | 55 | 320 | | |
| | | | | | |
| Order no. | b | C | D | dia. d1 | H | k | L | m | N | O |
| 94623 | 6 | 19 | 4,5 | 8 | 22,7 | 6 | 31 | 26,0-30,0 | 40 | 6,9 |
| 94649 | 6 | 19 | 5,5 | 10 | 22,7 | 13 | 40 | 31,3-35,8 | 45 | 10,9 |
| 94664 | 12 | 29 | 11,2 | 15 | 49,1 | 13 | 55 | 56,5-64,0 | 86 | 13,8 |
| | | | | | | | | | |
Also available in "STAINLESS STEEL" version (no. 6847GNI).
More Information | Order no. | 94664 |
|---|
| Product type | Hook type toggle clamp |
|---|
| Größe Schnellspanner | 5 |
|---|
