Coupling Plug, 13-pin
Without plug screw, without current bridge
Order no.
126326
Design:
Cylinder body made of tempering steel, phosphated. Piston case-hardened and ground, built-in return spring, with stroke limitation.
Application:
For quick clamping and unclamping on press table or ram. Suitable for workpieces with uniform clamping rim. The clamping bar is bolted with a spacer bar directly onto the press table or ram. Suitable spacer bars are No. 6945-22-04, -06, -07, -08.
On request:
Special sizes available on request.
| Order no. | 126326 |
|---|---|
| Product type | Remote control switches |
