Engagement screw
Suitable for compensating pull-stud no. 6370ZNAS size 10
| Order no. | Size | Holding force
[kN] | dia. D3
| L | L1 | L2 | m | Weight
[g] | Availability | Your Price |
| 571113 | 5 | 5 | 9 | 25 | 3,4 | 3,75 | M6 | 8 | | |
| 571114 | 10 | 10 | 12 | 45 | 7 | 8 | M8 | 30 | | |
| 571115 | 20 | 20 | 18 | 54 | 9 | 9,1 | M12 | 82 | | |
| 571116 | 40 | 30 | 23 | 68 | 10 | 8,6 | M16 | 153 | | |
| | | | | | | | | | |
More Information | Order no. | 571114 |
|---|
| Product type | Engagement screws |
|---|
| Operating mode | Pneumatic, Hydraulic |
|---|
| Size clamping module | 10 |
|---|
