Filter

Design:
Body from steel, zinc plated, filter sleeve made of aluminium, surfaces black anodised. Filter plates made of metal mesh.

Application:
The filter is used as on additional safety in order to protect the hydraulic components in the oil circuit. The filter can be located direct in pipelines, in front of distributors or in fittings.

Note:
The degree of soiling shall be checked. Thanks to the two-part housing, the exchange of the filter is simple. The flow direction can be on both sides. The installation position is optional. To tighten the G1/4 external thread, use the middle WAF19, when screwing the counterpart into the G1/4 internal thread, hold the WAF19 on the internal thread side.
Observe installation manuals.
Replacement part: filter insert 100 μm. Order No. 569996
