| Order no. | SW
[mm] | L1 x L2
[mm] | Weight
[g] | Availability | Your Price |
| 42358 | 1,5 | 46,5 x 15,5 | 0,9 | | |
| 42366 | 2,0 | 52,0 x 18,0 | 1,8 | | |
| 42374 | 2,5 | 58,5 x 20,5 | 3,0 | | |
| 42382 | 3 | 66 x 23 | 5,0 | | |
| 42390 | 4 | 74 x 29 | 10 | | |
| 42408 | 5 | 85 x 33 | 18 | | |
| 42416 | 6 | 96 x 38 | 30 | | |
| 42424 | 7 | 102 x 41 | 43 | | |
| 42432 | 8 | 108 x 44 | 59 | | |
| 42457 | 10 | 122 x 50 | 103 | | |
| 42473 | 12 | 137 x 57 | 160 | | |
| 42481 | 14 | 154 x 70 | 260 | | |
| 42499 | 17 | 177 x 80 | 430 | | |
| 42507 | 19 | 199 x 89 | 617 | | |
| 42515 | 22 | 222 x 102 | 920 | | |
| 42523 | 24 | 248 x 114 | 1238 | | |
| 42531 | 27 | 277 x 127 | 1740 | | |
| 42549 | 30 | 315 x 142 | 2410 | | |
| 42556 | 32 | 347 x 157 | 3080 | | |
| 42564 | 36 | 391 x 176 | 4370 | | |
| 42572 | 0,7 | 33 x 7 | 0,14 | | |
| 42580 | 0,9 | 33 x 11 | 0,2 | | |
| 43067 | 1,3 | 41 x 13 | 0,7 | | |
| | | | | |
On request:
Other lengths and executions on request.
The 1.3 A/F key is in fact 1.27 mm, which is precisely 0.05".
More Information | Order no. | 42499 |
|---|
| Key width [mm] | 17 |
|---|
| Finishing | Blued |
|---|
Pimcore content from synoa_downloadsnk_downloads_tab_top
| Area | Language | File name | Type | File size | |
Pimcore content from synoa_downloadsnk_downloads_tab_bottom
Similar products
Key box (mm) Nr. 44867 Contents (A/F): ISO 2936-2, 2.5; DIN 6911-3, 4, 5, 6, 8 mm
