Hinged hook wrench with pin, industrial version
Blued, ⌀ nut 16-22 mm, ⌀ pin 2,5 mm
Order no.
53058
Advantage:
- Longer shaft permits higher torque
- Lengthened cant dog ensures complete wrapping and safe handling
- Reinforced rivet increases working life and permits transmission of greater forces, especially with smaller sizes
- Even movement due to additional spring washer, one-handed operation possible
- Improved fit of the hooks with journal thickness and nut diameters.
Sizes 16-22 without retaining ring.
| Order no. | 53058 |
|---|---|
| Veredelung | Blued |
| Muttergröße min. [mm] | 16 |
| Muttergröße max. [mm] | 22 |
| Zapfendurchmesser [mm] | 2.5 |
| Besondere Merkmale | With hinge |
| Weight [g] | 50 |
