Rotary vane vacuum pump
For compressed air at the place of use
Order no.
563547
Design:
Vacuum connection Ø = 20 mm
Application:
If there is no compressed air at the place of use of the vacuum clamping plate, we recommend using the AMF rotary vane vacuum pump. It guarantees reliable continuous operation of the clamping plates used. Thanks to the compact design of the pump, it can be installed directly on your machine.
Note:
Replacement oil can be ordered under order no. 428722.
Oil filling quantity 0.45 l.
On request:
Other sizes and suction performances are available on request.
| Order no. | 563547 |
|---|
Pimcore content from synoa_downloadsnk_downloads_tab_top
| Area | Language | File name | Type | File size |
|---|
Pimcore content from synoa_downloadsnk_downloads_tab_bottom
Suitable accessories
- Liquid separator with vacuum filter Nr. 374975 Removes condensate (water) from the vacuum clamping system
Similar products
- Venturi nozzle connecting set Nr. 567156 For easy connection of the vacuum clamping plate to the compressed air system
