Tapered clamp with adjusting support screw
For clamping screw M36/M42, clamping height 24-150 mm
Order no.
374439
*depending on depth of slot to DIN 650 and position of fixture nut.
Clamps without T-bolts are same item for sizes 12 and 14, 16 and 18, 20 and 22, each.
Clamps without T-bolts are same item for sizes 12 and 14, 16 and 18, 20 and 22, each.
| Order no. | 374439 |
|---|---|
| Clamping screw | Without clamping bolt |
| Clamping screw metric [M] | 36, 42 |
| Min. clamping height [mm] | 24 |
| Max. clamping height [mm] | 150 |
