Vertical axis
For fastening an extremely wide range of system elements, height 80 mm
Order no.
568787
Application:
Vertical axes for screwing onto the base plate as a basis for fastening different system elements.
Features:
- Hardened bolt made of wear-resistant case-hardened steel
- Hardened and burnished base element made of wear-resistant case-hardened steel
- Hexagonal T-nut for optimum carrying capacity
- Bolt secured against twisting
- The adapted elements can be clamped continuously in the Z and C-axes
Note:
Observe tightening torque.
| Order no. | 568787 |
|---|---|
| Product type | Vertikalachsen |
