Air gun valve, pneumatic
For simple and quick opening of the pneumatic zero point clamping plates
Order no.
533075
Design:
Pneumatic air gun with integrated non-return valve.
Application:
For simple and quick opening of the pneumatic zero point clamping plates. When the air gun is positioned on the valve, the air pressure is released and then held by the non-return valve. Venting is effected by briefly and manually pushing the valve, which then resets under spring force.
Note:
The tip of the blow out nozzle should have a 45° angle and a smooth surface (no fan nozzle).
| Order no. | 533075 |
|---|---|
| Product type | Installation clamping modules, Surface-mounting clamping modules, Clamping stations |
| Operating mode | Pneumatic |
| Size clamping module | 5, 10, 20, 40, 140/141, 150/151, 250/251, 260, 270 |
