Clamp with nose, closed
For clamping screw metric M24 and inch 1, length 500 mm
| Order no. | B1 | L | for
clamping screw
metric | for
clamping screw
inch | A | b2 | B3 | E1 | E2 | L3 | Weight
[g] | Availability | Your Price |
| 376145 | 22 | 250 | M20 M22 | 3/4 | 40 | 60 | 35 | 68 | 160 | 45 | 3025 | | |
| 376160 | 22 | 315 | M20 M22 | 3/4 | 40 | 60 | 35 | 68 | 220 | 45 | 3810 | | |
| 376186 | 22 | 400 | M20 M22 | 3/4 | 50 | 60 | 35 | 68 | 300 | 45 | 5995 | | |
| 376202 | 22 | 500 | M20 M22 | 3/4 | 50 | 60 | 35 | 68 | 400 | 45 | 7440 | | |
| 376228 | 26 | 250 | M24 | 1 | 40 | 70 | 43 | 83 | 140 | 56 | 3639 | | |
| 376244 | 26 | 315 | M24 | 1 | 40 | 70 | 43 | 83 | 200 | 56 | 4560 | | |
| 376269 | 26 | 400 | M24 | 1 | 50 | 70 | 43 | 83 | 270 | 56 | 7243 | | |
| 376285 | 26 | 500 | M24 | 1 | 50 | 70 | 43 | 83 | 370 | 56 | 8937 | | |
| 376301 | 33 | 315 | M30 | 1 1/4 | 50 | 80 | 50 | 88 | 200 | 56 | 6367 | | |
| 376327 | 33 | 400 | M30 | 1 1/4 | 50 | 80 | 50 | 88 | 283 | 56 | 7798 | | |
| 376343 | 33 | 500 | M30 | 1 1/4 | 50 | 80 | 50 | 88 | 383 | 56 | 9607 | | |
| | | | | | | | | | | | | |
More Information | Order no. | 376285 |
|---|
| Clamping screw | Without clamping bolt |
|---|
| Clamping screw metric [M] | 24 |
|---|
| Clamping screw inch | 1 |
|---|
If you are missing a download, please write to us using our contact form.
| Area | Language | File name | Type | File size | |
Similar products
Clamp, cranked Nr. 71118 For clamping screw metric M24 and inch 1, length 250 mm
Clamp, flat Nr. 70102 For clamping screw metric M24 and inch 1, length 250 mm
