| Order no. | Article no. | Slot | A1 x B1 x C1 | H4 | SW1 | SW2 | Weight
[g] | Availability | Your Price |
| 79533 | 7100BR-20x22 | 22 | 40 x 60 x 195 | 242 | 30 | 36 | 9430 | | |
| 79541 | 7100BR-20x24 | 24 | 40 x 60 x 195 | 242 | 30 | 36 | 9570 | | |
| 79558 | 7100BR-20x28 | 28 | 40 x 60 x 195 | 242 | 30 | 36 | 9700 | | |
| 79566 | 7100BR-30x28 | 28 | 80 x 80 x 330 | 381 | 46 | 55 | 31300 | | |
| 79582 | 7100BR-30x36 | 36 | 80 x 80 x 330 | 381 | 46 | 55 | 32000 | | |
| | | | | | | | | |
| Order no. | A | dia. B
| b2 | C | dia. D
| E | F | F1 | G | H1 | H2 | H3 | I | k | L | m | dia. N | dia. N1 | P | R |
| 79533 | 40 | 45 | 65 | 150 | 30 | 260 | 35 | 55 | M20 | 121-171 | 156-206 | 101-151 | 65 | 40 | 105 | M24 | 24 | 36 | 43-96 | 10 |
| 79541 | 40 | 45 | 65 | 150 | 30 | 260 | 35 | 55 | M20 | 121-171 | 156-206 | 101-151 | 65 | 40 | 105 | M24 | 24 | 36 | 43-96 | 10 |
| 79558 | 40 | 45 | 65 | 150 | 30 | 260 | 35 | 55 | M20 | 121-171 | 156-206 | 101-151 | 65 | 40 | 105 | M24 | 24 | 36 | 43-96 | 10 |
| 79566 | 60 | 60 | 80 | 270 | 40 | 460 | 50 | 75 | M30 | 205-280 | 255-330 | 180-255 | 90 | 55 | 210 | M30 | 33 | 48 | 60-174 | 15 |
| 79582 | 60 | 60 | 80 | 270 | 40 | 460 | 50 | 75 | M30 | 205-280 | 255-330 | 180-255 | 90 | 55 | 210 | M30 | 33 | 48 | 60-174 | 15 |
| | | | | | | | | | | | | | | | | | | | |
More Information | Order no. | 79582 |
|---|
| Type | 30 |
|---|
| Max. height [mm] | 255 |
|---|
| Min. height [mm] | 180 |
|---|
