Fork clamp
Fits M16 x grid 50 mm
Order no.
300343
Application:
The support element is used as an additional support, in modular or special fixtures, to prevent flexing and vibration of a workpiece. It enables large workpiece tolerances (castings) to be accommodated. Mounted directly under a clamping point, it prevents distortion of a workpiece. Secure positioning is ensured by a spring.
| Order no. | 300343 |
|---|
If you are missing a download, please write to us using our contact form.
| Area | Language | File name | Type | File size |
|---|
For general downloads, such as catalogs and brochures, please click here.
Suitable accessories
- Support pin Nr. 300459 Support height (in conjunction with supporting element no. 300335) 58-64 mm, length 25 mm
