Forked clamp with shoe
For clamping screw metric M24 and inch 1, length 250 mm
| Order no. | B1 | L1 | for
clamping screw
metric | for
clamping screw
inch | A | b2 | B3 | L2 | L3 | Weight
[g] | Availability | Your Price |
| 70862 | 9 | 100 | M8 | 5/16 | 15 | 30 | 16 | 32 | 18 | 240 | | |
| 70870 | 11 | 125 | M10 | 3/8 | 20 | 30 | 20 | 38 | 24 | 380 | | |
| 70888 | 14 | 160 | M12 M14 | 1/2 | 25 | 40 | 24 | 47 | 30 | 800 | | |
| 70896 | 14 | 200 | M12 M14 | 1/2 | 25 | 40 | 24 | 47 | 30 | 950 | | |
| 70904 | 18 | 200 | M16 M18 | 5/8 | 30 | 50 | 28 | 57 | 36 | 1500 | | |
| 70912 | 18 | 250 | M16 M18 | 5/8 | 30 | 50 | 28 | 57 | 36 | 1850 | | |
| 70920 | 22 | 250 | M20 M22 | 3/4 | 40 | 60 | 35 | 68 | 45 | 2900 | | |
| 70938 | 22 | 315 | M20 M22 | 3/4 | 40 | 60 | 35 | 68 | 45 | 3600 | | |
| 70946 | 26 | 250 | M24 | 1 | 40 | 70 | 43 | 83 | 56 | 3400 | | |
| 70953 | 26 | 315 | M24 | 1 | 40 | 70 | 43 | 83 | 56 | 4300 | | |
| 70961 | 33 | 315 | M30 | 1 1/4 | 50 | 80 | 50 | 88 | 56 | 6000 | | |
| 70979 | 33 | 400 | M30 | 1 1/4 | 50 | 80 | 50 | 88 | 56 | 7300 | | |
| | | | | | | | | | | | |
More Information | Order no. | 70946 |
|---|
| Clamping screw | Without clamping bolt |
|---|
| Clamping screw metric [M] | 24 |
|---|
| Clamping screw inch | 1 |
|---|
