Loose pin with nut
Blued, ⌀ pin 10 mm, thread size M8
| Order no. | dia. D* | dia. d1 | L | m | Usage 764AZ/764Md/764CC | Weight
[g] | Availability | Your Price |
| 47787 | 5 | 8,5 | 5,5 | M 6 | 40-80 / 80-125 | 5 | | |
| 47795 | 3 | 5,5 | 4,0 | M 4 | 18-40 | 2 | | |
| 47803 | 4 | 7,0 | 5,0 | M 4 | 18-40 | 2 | | |
| 47845 | 6 | 10,0 | 6,5 | M 6 | 40-80 / 80-125 | 7 | | |
| 47852 | 7 | 11,0 | 7,0 | M 6 | 40-80 / 80-125 | 8 | | |
| 47860 | 8 | 12,0 | 7,5 | M 6 | 40-80 / 80-125 | 9 | | |
| 47878 | 8 | 12,0 | 7,5 | M 8 | 125-200 | 14 | | |
| 47886 | 10 | 15,0 | 9,5 | M 8 | 125-200 | 19 | | |
| 50328 | 4 | 8,5 | 4,5 | M 6 | 40-80 / 80-125 | 3 | | |
| | | | | | | | |
* Pin diameter = nominal diameter -0.1 mm (tolerance class h12)
More Information | Order no. | 47886 |
|---|
| Finishing | Blued |
|---|
| Pin spacing min. [mm] | 125 |
|---|
| Pin spacing max. [mm] | 200 |
|---|
| Pin diameter [mm] | 10 |
|---|
| Special features | With replaceable pins |
|---|
