Pull-stud size 20 for M12 engagement screw without fitting collar
For clamping modules size 20, suitable for engagement screw 6370ZNSF
Order no.
562767
Design:
Order no. 562767: Zero-point pull-stud
Application:
For clamping workpieces in a threaded hole without a fitting collar.
Used only in conjunction with the construction kit system.
| Order no. | 562767 |
|---|---|
| Product type | Pull-studs |
| Operating mode | Mechanical, Hydraulic, Pneumatic |
| Size clamping module | 20 |
