Quick-action clamping nut without collar
Thread M12, key width 27 mm, test force 59 kN
Order no.
88567
Application:
Slide quick-action clamping nut directly over screw thread up to clamping point and then lock it. If the quick-action clamping nut base is firmly in contact at the clamping point, then the head can be locked with the base by means of a 1/4 to 1/2 turn.
Note:
For test force see EN ISO 898-2
Advantage:
- time-saving in the case of long and damaged studding
- easy assembly/disassembly at narrow and non-visible places
- no seizing up on the thread by external influences
- no impairment by soiling such as paint residues or rust
| Order no. | 88567 |
|---|---|
| Product type | Quick-action clamping nuts |
| Thread [M] | 12 |
| Strength class | 6 |
