Safety bolt for collet attachment - outside clamping
Size 20, Ø 22,7 mm
Order no.
568512
Application:
To attach the workpiece contour, the collet attachment for outside clamping must be clamped with the safety bolt.
| Order no. | 568512 |
|---|---|
| Operating mode | Mechanical |
| Special features | Outside clamping |
Pimcore content from synoa_downloadsnk_downloads_tab_top
| Area | Language | File name | Type | File size |
|---|
Pimcore content from synoa_downloadsnk_downloads_tab_bottom
Suitable accessories
- Collet attachment outside clamping Nr. 567124 Size 20, Ø 90 - 99 mm, material made of high-strength aluminium, hard anodised (EN AW 7075)
