Shuttle Valve
For pipe connection, max. operating pressure 630 bar, volume flow 18 l/min, differential pressure 12 bar
Order no.
62984
Design:
Housing made of steel, surface galvanized. Ball seat valve type.
Application:
By means of two input connections which can be shut and an output connection the alternating valve connects A or B with C according to the present pressurized line; the other connection is closed by means of a ball.
Note:
Attention: The hydraulic line empties itself when not under pressure. The pipe connection is sealed by means of a cutting ring.
| Order no. | 62984 |
|---|---|
| Product type | Shuttle valve |
| Max. operating pressure [bar] | 630 |
| Oil port | Pipe |
| Volume flow [l/min] | 18 |
If you are missing a download, please write to us using our contact form.
| Area | Language | File name | Type | File size |
|---|
For general downloads, such as catalogs and brochures, please click here.
Suitable accessories
- Screw-in fitting, straight, heavy-duty Nr. 112714 For steel tubes with outer diameter 8 mm and internal diameter 4 mm, with olive ring, max. operating pressure 400 bar
- Pivoting fitting, angled, heavy-duty Nr. 112961 For steel tubes with outer diameter 8 mm and internal diameter 4 mm, with olive ring, max. operating pressure 400 bar
- Pivoting T-fitting, heavy-duty Nr. 116418 For steel tubes with outer diameter 8 mm and internal diameter 4 mm, with olive ring, max. operating pressure 400 bar
- Bulkhead fitting, straight, heavy-duty Nr. 131631 For steel tubes with outer diameter 8 mm and internal diameter 4 mm, with olive ring, max. operating pressure 800 bar
- Union nut with cutting ring, heavy series Nr. 184150 For steel tubes with outer diameter 8 mm and internal diameter 4 mm, with olive ring, max. operating pressure 800 bar
