Wedge block Herkules height wedge
Application:
The fine-machined wedge surfaces permits a smooth, precise adjustment to less than 1/10 mm. The double wedge effect produces a large stroke and precise vertical movement with no lateral shift. The height wedge proves its worth with heavy castings or forgings on large tool machines. The AMF "Herkules" whipstock has an additional centring hole in the floor of the base area.
Note:
Suitable attachments for wedge block No. 6460 are No. 6440, 6440G, 6441 and 6442.
All sizes with lateral clamping rim for fastening on the machine table.
For size 63, the base plate is removable for reaching Hmin.
Advantage:
For the sizes 125 and 190, the attachment 6440G can be screwed in so it cannot be lost.
*H/U= height adjustment per single turn.
| Order no. | 72793 |
|---|---|
| Product type | Wedge block |
| Min. height [mm] | 170 |
| Max. height [mm] | 190 |
| Max. support force [kN] | 250 |
Pimcore content from synoa_downloadsnk_downloads_tab_top
| Area | Language | File name | Type | File size |
|---|
Pimcore content from synoa_downloadsnk_downloads_tab_bottom
- Precision wedge block Nr. 375592 Size 55, centring hole Ø12 mm, height 50-55 mm, max. clamping force 40 kN, width 80 mm, length 128 mm
- Height adjustment jack with fine thread and base element 6425FB Nr. 562001 Height 210-330 mm, max. support force 35 kN
- Support element, mechanical Nr. 75416 Incl. nut for T-grooves DIN 508-M12x14, height 78-33 mm, stroke 5 mm
