Clamp, flat
For clamping screw metric M10 and inch 3/8, length 80 mm
Order no.
70029
* Size not included in DIN, dimensions similar to DIN
| Order no. | 70029 |
|---|---|
| Clamping screw | Without clamping bolt |
| Clamping screw metric [M] | 10 |
| Clamping screw inch | 3/8 |
