Clamp, flat
For clamping screw metric M12/M14 and inch 1/2, length 125 mm
Order no.
70045
* Size not included in DIN, dimensions similar to DIN
| Order no. | 70045 |
|---|---|
| Clamping screw | Without clamping bolt |
| Clamping screw metric [M] | 12, 14 |
| Clamping screw inch | 1/2 |
