| Order no. | Size | for jaw
width
| Clamping force
[kN] | Clamping stroke
[mm] | Weight
[g] | Availability | Your Price |
| 300863 | 4109-50 | 50 | 12 | 2 | 390 | | |
| 300889 | 4119-80 | 80 | 15 | 2 | 1430 | | |
| | | | | | | |
| Order no. | A | b | C | D | E | F | G | H | J | k | L | m | N | T | U | V |
| 300863 | 49 | 20 | 17 | 43 | 30,7 | 6 | 12,4 | 8 | 8,5 | 18,5 | 5,5 | 6xM5 | 2xM6 | 6,3 | 5 | 31 |
| 300889 | 78 | 32,2 | 22 | 64 | 48 | 8 | 19 | 8 | 11 | 31,5 | 6 | 6xM6 | 2xM6 | 8 | 7 | 46 |
| | | | | | | | | | | | | | | | |
More Information | Order no. | 300863 |
|---|
| Operating mode | Mechanical |
|---|
| Backenbreite | 50 |
|---|
