| Order no. | Size | for jaw
width
| Clamping force
[kN] | Clamping stroke
[mm] | Weight
[g] | Availability | Your Price |
| 265835 | 4102-50 | 50 | 12 | 2 | 373 | | |
| 266825 | 4110-80 | 80 | 15 | 2 | 1446 | | |
| | | | | | | |
| Order no. | A | b | C | D | E | F | G | H | J | k | L | m | N | T | U | V |
| 265835 | 49 | 20 | 17 | 40 | 33,7 | 3 | 12,4 | 8 | 8,5 | 18,5 | 5,5 | 6xM5 | 2xM6 | 3,3 | 5 | 28 |
| 266825 | 78 | 32,2 | 22 | 60 | 52 | 4 | 19 | 8 | 11 | 31,5 | 6,0 | 6xM6 | 2xM6 | 4 | 7 | 42 |
| | | | | | | | | | | | | | | | |
More Information | Order no. | 265835 |
|---|
| Operating mode | Mechanical |
|---|
| Backenbreite | 50 |
|---|
If you are missing a download, please write to us using our contact form.
| Area | Language | File name | Type | File size | |
