Counterbalance element XY-plane
Size B10
Order no.
558905
Application:
The counterbalance element can compensate for a position tolerance of up to 4 mm in the plane. It is used to compensate for distance tolerances of the pull-studs. The upper part can be pushed to the base in the opened condition and is clamped without twisting by actuating the clamping screw.
Note:
The fastening bolts are supplied as standard.
Advantage:
Simple, quick and flexible clamping on the machine table of complex workpiece contours with large pull-stud distance tolerances.
| Order no. | 558905 |
|---|---|
| Product type | Modular zero-point clamping system |
| Operating mode | Mechanical |
| Size clamping module | 10 |
