Filter plate
Used to protect the 6966D-07 clamp from contamination in clamping devices
Order no.
562218
Design:
Filter plate and filter sleeve made of aluminium, black anodised.
Filter plates made of metal mesh.
Application:
Used to protect the 6966D-07 clamp from contamination in clamping devices.
Note:
If a finer strainer is required, this can be easily replaced.
The finer the filter selected, the greater the flow resistance.
Replacement filter:
Filter, plug-in design 25 μm, order no. 562203
Filter, plug-in design 40 μm, order no. 562204
Filter, plug-in design 100 μm, order no. 562205
| Order no. | 562218 |
|---|---|
| Max. operating pressure [bar] | 250 |
| Max. piston force [kN] | 7.8 |
| Max. holding force [kN] | 6.7 |
| Type of actuation | Double acting |
