Gauge
Bottom connection, max. operating pressure 100 bar
Order no.
320648
Design:
Complete with glycerin filling and aluminium sealing ring. Accuracy class 1.6.
Housing made of stainless steel, rust-free.
Note:
A combination of pipe fitting 6994-01 and 6994-02 can be used for the pipe connection.
| Order no. | 320648 |
|---|---|
| Product type | Pressure gauge and manifold |
| Max. operating pressure [bar] | 100 |
| Oil port | Thread |
