Spacer element
Size 30, slot 14 mm, grid plate M12, height 60 mm
| Order no. | Size | m | Slot | H | H2 | L | Weight
[g] | Availability | Your Price |
| 554821 | 30 | M12 | 14 | 66 - 128 | 60 | 135 | 2300 | | |
| 554822 | 32 | M12 | 14 | 66 - 110 | 60 | 95 | 1570 | | |
| 554823 | 40 | M16 | 18 | 76 - 120 | 70 | 110 | 2290 | | |
| 554824 | 43 | M16 | 18 | 75 - 150 | 70 | 155 | 3344 | | |
| 554825 | 49 | M20 | 22 | 87 - 168 | 80 | 175 | 5286 | | |
| 556407 | 22 | M12 | 14 | 40 - 73 | 35 | 65 | 480 | | |
| 562185 | 22 | M10 | 12 | 40 - 73 | 35 | 65 | 480 | | |
| | | | | | | | | |
More Information | Order no. | 554821 |
|---|
| Product type | Power clamp |
|---|
| Size/load static [kN] | 30 |
|---|
| Slot [mm] | 14 |
|---|
Pimcore content from synoa_downloadsnk_downloads_tab_top
| Area | Language | File name | Type | File size | |
Pimcore content from synoa_downloadsnk_downloads_tab_bottom
Similar products
Power clamp 3-step Nr. 559879 Size 30, max. load static 30 kN, grid plate M12, height 13-129 mm
