Spacer element
Size 22, slot 14 mm, grid plate M12, height 35 mm
Order no.
556407
Note:
- Use only the corresponding AMF mounting kit 7600BFS.
- If the clamping element without T-slot nut DIN 508 is used, the tensile strength of the support plate must be at least 900 N/mm²!
Advantage:
- Additional clamping heights can be achieved by installing multiple spacer elements
- Continuous transition between the clamping heights
- For use in T-slots 12 - 28 mm and/or grid plates M10, M12, M16, M20
| Order no. | 556407 |
|---|---|
| Product type | Power clamp |
| Size/load static [kN] | 22 |
| Slot [mm] | 14 |
