Thread adapter
Thread M20, height 91,5 mm
Order no.
562009
Application:
The thread adapters are screwed in the base element 6425FB and can thus be used on T-slots and grid plates. The insertion tool makes it easy to use the thread adapter.
| Order no. | 562009 |
|---|---|
| Product type | Modular screw jack |
| Min. height [mm] | 29.5 |
| Max. height [mm] | 29.5 |
If you are missing a download, please write to us using our contact form.
| Area | Language | File name | Type | File size |
|---|
For general downloads, such as catalogs and brochures, please click here.
Suitable accessories
- Screw jack element with acme thread and base element 6425FB Nr. 562002 Centring hole diameter 12 mm, height 306-406 mm
- Insertion tool Nr. 562014 Makes it possible to use the head and base elements of the screw jack modular as well as thread adapter
