Swing Clamp Arm, standard
Design:
Cylinder body from steel, burnished. Piston rod nitrided. Wiper at piston rod. Built-in return spring. Supply scope includes clamping lever pin, but not clamping lever. Oil supply via oil channel in fixture body.
Application:
This vertical clamp can be used for clamping in cavities or in very tight spaces.
Features:
Small dimensions, can be installed closely spaced side-by-side. The clamping levers can be exchanged easily in the installed position.
Note:
Screws according to ISO4762 M6, strength class 12.9, lightly oiled, tightening torque Md = 18 Nm not supplied as standard.
During unclamping, the vertical clamp allows a max. dynamic pressure of 3 bar, which must be strictly taken into account when using control valves.
| Order no. | 60848 |
|---|
