Adapter Plate, light duty
For steel pipes, external ø 6 or 8 mm, internal ø 3 or 4 mm, with cutting ring, max. operating pressure 315 bar
Order no.
320846
Design:
Pipe connection seal with cutting ring in acc. with ISO 8434-1 / DIN 2353.
Note:
Warning: Do not use Teflon tape!
| Order no. | 320846 |
|---|---|
| Product type | Hose fittings |
| Max. operating pressure [bar] | 315 |
| Oil port | Thread, Pipe |
If you are missing a download, please write to us using our contact form.
| Area | Language | File name | Type | File size |
|---|
For general downloads, such as catalogs and brochures, please click here.
Suitable accessories
- Union nut with cutting ring, light duty Nr. 313361 For steel tubes with outer diameter 6 mm and internal diameter 3 mm, with olive ring, max. operating pressure 315 bar
